CP.DIVA

APPLICATION

1 road barrier: DIVA

CONTROL UNIT POWER SUPPLY

115 or 230 Vac – 50/60 Hz

MOTORS POWER SUPPLY

24 Vdc – 11 A three-phase brushless

MAIN FUNCTIONS

Integrated LCD Display I Integrated 433.92 MHz 512-codes radio receiver with ARC coding I Removable terminal boards I Automatic, semi-automatic and HTR logic I Step by step, stop, photocell, open and close inputs I Outputs configurable as open barrier indicator, second radio channel, boom lights, courtesy light, verified photocell power supply, maintenance indicator, close contact when the barrier is open or closed I Autoset of operation parameters I Electronic torque adjustment with automatic calculation for each point of the stroke (STC SYSTEM) I Separate electronic adjustments of opening and closing speeds I Anti-crushing safety through amperometric detection and encoder management I Electronic slowdowns in opening and closing I Preparation for the operation of opposed barriers with SIS synchronisation board (optional) I Set up for connection to KNX systems via X.BE card (optional) I Designed for managing, configuring, diagnosing and updating firmware through the BeUP app, using the PRO.UP accessory I Advantouch system to configure parameters and manage radio transmitters I Number of manoeuvres I Programming access password I Maintenance warning I Built-in battery charger compatible with batteries DA.BT2 / DA.BT6.
