CP.EVA

APPLICATION

1 road barrier: EVA.5, EVA.7 & EVA.8

CONTROL UNIT POWER SUPPLY

100 – 250 Vac – 50/60 Hz

MOTORS POWER SUPPLY

24 Vdc – 10 A

MAIN FUNCTIONS

Integrated LCD display I Integrated 433.92 MHz 64-code radio receiver with 3 encoding systems (Advanced Rolling Code, Rolling Code, Fixed Code) I Absolute encoder management I Removable terminal boards I Automatic, semi-automatic and HTR logic I Motor limit switch inputs I Open, close, step by step, photocell and stop inputs I Output for EVA.L accessory, integrated LED on arm I Output configurable as open barrier indicator light, second radio channel of incorporated receiver, arm light, service light, photocell test or maintenance indicator I Output for connecting flashing light I Predesigned for the operation of opposed barriers with SIS synchronisation board (optional) I Autosetting of operation parameters I Electronic torque adjustment with automatic calculation for each point in the stroke (STC SYSTEM) I Anti-crushing safety thanks to amperometric obstacle detection I Adjustable slow-downs I Number of manoeuvres I Programming access password I Maintenance warning I Integrated battery charger, compatible with battery models DA.BT2/DA.BT6.
